METINNO Nexus® 92

Heavy Duty Centreline Glazing System

Meet the METINNO Nexus® Series — a heavy-duty centreline glazing aluminium partitioning suite designed for commercial and architectural environments where strength, consistency and a refined finish are essential.

METINNO Nexus® 92 (NX92) is designed to suit 92mm steel stud with 13mm plasterboard on each side. It features a 43 mm profile that suits up to 12.38mm glass, offering seamless integration and an elegant, minimalist aesthetic.

Available in a natural anodised or mill finish for powder coating to any colour.

See also METINNO Nexus® 64 (NX64) and METINNO Nexus® 76 (NX76).

  • Heavy-duty Centreline glazing design
  • Designed for 92mm steel stud with 13mm plasterboard each side
  • 43mm profile that suits up to 12.38mm glass
  • Similar side profile to shop front
  • Sleek, minimalist finish complements modern architectural interiors
  • Available in 6.5m lengths in both natural anodised and mill finish
Book-open Book-open Brochure

Did you know we offer a Fabrication service?

ADX Depot can have your aluminium fabricated to suit project specific designs. Get in touch for more info, pricing & availability…

Enquire

NX92 SectionsNXDS Door Connectors
PreviousNext

METINNO Nexus® 92 Sections

NX9200 (Main Glazing Frame)

The main glazing frame features integrated fins for simple installation and increased stability in plasterboard partition systems where glazing is required.

Connects with: NX9204
Available Length: 6.5m (Natural Anodised & Mill Finish)

NX9201 (Main Door Frame)

The main door frame features integrated fins for simple installation and increased stability in plasterboard partition systems where doors are required. Offset pocket to suit clip-in door stops.

Connects with: NX9204, NXDS35, NXDS40, NXDS45
Available Length: 6.5m (Natural Anodised & Mill Finish)

NX9202 (Sill Transom)

Adaptable glazing sill section that can also integrate with a steel track where half-height walls are required.

Connects with: NX9203
Available Length: 6.5m (Natural Anodised & Mill Finish)

NX9203 (Sill Bead)

Clip in bead for ease of glazing.

Connects with: NX9202
Available Length: 6.5m (Natural Anodised & Mill Finish)

NX9204 (Glazing Adaptor)

When combined with the NX9200 section, the NX9204 creates a mullion designed to accommodate glazing on both sides. Additional wings for screw fixing.

Connects with: NX9200, NX9201
Available Length: 6.5m (Natural Anodised & Mill Finish)

METINNO Nexus® Door Connectors

NXDS35 (35mm Door Stop)

Maintains a uniform and attractive partition system, whilst promoting high quality acoustics. To suit 35mm door.

Connects with: NX6401, NX7601, NX9201
Available Length: 6.5m (Natural Anodised & Mill Finish)

NXDS40 (40mm Door Stop)

Maintains a uniform and attractive partition system, whilst promoting high quality acoustics. To suit 40mm door.

Connects with: NX6401, NX7601, NX9201
Available Length: 6.5m (Natural Anodised & Mill Finish)

NXDS45 (45mm Door Stop)

Maintains a uniform and attractive partition system, whilst promoting high quality acoustics. To suit 45mm door.

Connects with: NX6401, NX7601, NX9201
Available Length: 6.5m (Natural Anodised & Mill Finish)

NXPF (Pocket Filler)

Pocket filler for all glazing pocket systems. Clips in for easy installation.

Connects with: NX6401, NX7600, NX7601, NX9200, NX9201
Available Length: 6.5m (Natural Anodised & Mill Finish)
